800W 60V DC Speed Controller Box for Scooter Electric Bike Brush Motor
800W 60V DC Speed Controller Box for Scooter Electric Bike Brush Motor is backordered and will ship as soon as it is back in stock.
Highlight title
Text to highlight a key feature of your product
Description
Description
Controller for Electric Scooter, 60V 12A, 800W
Works on 60V, 800W scooters and electric bikes
Type: brush speed controller
Voltage: 36V
Wattage: 800W
Casing material: aluminium
Colour: silver
Dimensions: 122 x 97 x 50mm
Plug :
1.Red & Black (large cable) : Battery connections
2.Yellow & Blue : Motor connections
3.Red & Blue : Key Switch(power lock) (If there is no power door locks,red connection to blue)
4.Yellow & black : brake
5.Red & Yellow: Brake light
6.Red&Black(small cable) : indicator light
7.Red, Black & Blue: Speed Regulator 1-4 V(Throttle ) (Red:+5v,Black: - ,Blue :Signal Wire)
8.Red & Black (small cable): Charger
